Model
|
CPD40
|
CPD45
|
CPD50
|
|
Configuration number
|
-
|
GB25U
|
-
|
|
Load capacity（Q）
|
8000 lb4000 kg
|
9000 lb4500 kg
|
10000 lb5000 kg
|
|
Load center distance（c）
|
24 in600 mm
|
24 in600 mm
|
24 in600 mm
|
|
Power mode
|
Lithium battery
|
Lithium battery
|
Lithium battery
|
|
Driving mode
|
Seated
|
Seated
|
Seated
|
|
Wheel base（L1）
|
77.2 in1960 mm
|
77.2 in1960 mm
|
77.2 in1960 mm
|
|
Tyre type
|
Solid tyre
|
Solid tyre
|
Solid tyre
|
|
Wheel number (front/rear)
|
2/2
|
2/2
|
2/2
|
|
Front wheel base（W3）
|
44.1 in1120 mm
|
44.1 in1120 mm
|
46.8 in1189 mm
|
|
Rear wheel base（W4）
|
42.1 in1070 mm
|
42.1 in1070 mm
|
42.1 in1070 mm
|
|
Tyre (front) Size
|
250 - 1521×9 - 9
|
250 - 1521×9 - 9
|
28×12.5 - 1521×9 - 9
|
|
Front overhang（L2）
|
22 in560 mm
|
22 in560 mm
|
22 in560 mm
|
|
Mast tilt angle (front/rear)（α/β）
|
88.2°/88°2240 mm
|
88.2°/88°2240 mm
|
87.8°/88°2230 mm
|
|
Height with mast retraction（H1）
|
5.9 in150 mm
|
5.9 in150 mm
|
5.9 in150 mm
|
|
Free lifting height（H3）
|
158.1 in3000 mm
|
158.1 in3000 mm
|
158.1 in3000 mm
|
|
Max.lifting height（H）
|
166.7 in4225 mm
|
166.7 in4225 mm
|
166.3 in4225 mm
|
|
Max.height under working condition（H2）
|
89.6 in2275 mm
|
89.6 in2275 mm
|
89.4 in2275 mm
|
|
Fork size: thickness×width×length（TXWXL4）
|
2 - 6×42 in50×150×1070 mm
|
2 - 6×42 in50×150×1070 mm
|
2 - 6×42 in50×150×1070 mm
|
|
Fork size according with ISO 2328, class/type A, B
|
3A
|
3A
|
3A
|
|
Truck body length (fork excluded)（L'）
|
115 in2920 mm
|
115 in2920 mm
|
115 in2920 mm
|
|
Truck body width（W1）
|
53.1 in1350 mm
|
53.1 in1350 mm
|
53.1 in1350 mm
|
|
Turning radius（r）
|
101.6 in2580 mm
|
101.6 in2580 mm
|
101.6 in2580 mm
|
|
Clearance between mast and ground（H5）
|
5.7 in145 mm
|
5.7 in145 mm
|
5.3 in135 mm
|
|
Clearance between wheel base center and ground (loaded)（H6）
|
170.9 in4340 mm
|
170.9 in4340 mm
|
170.9 in4340 mm
|
|
Right angle stacking aisle width (pallet 1000×1000mm, clearance 200mm)（Ast）
|
178.7 in4540 mm
|
178.7 in4540 mm
|
178.7 in4540 mm
|
|
Performance
|
|
|
|
|
Travelling speed (loaded/unloaded)
|
88.7 mph1314 ftpm
|
88.7 mph1314 ftpm
|
88.7 mph1314 ftpm
|
|
Lifting speed (loaded/unloaded)
|
61/68.7 fpm310/450 mm/s
|
55.2/88.7 fpm280/450 mm/s
|
51.2/88.7 fpm260/450 mm/s
|
|
Lowering speed (loaded/unloaded)
|
98.5/88.7 fpm500/450 mm/s
|
98.5/88.7 fpm500/450 mm/s
|
98.5/88.7 fpm500/450 mm/s
|
|
Gradeability (loaded/unloaded)
|
16/27 %
|
15/26 %
|
14/25 %
|
|
Max.traction force (loaded)
|
21000 N
|
21000 N
|
21000 N
|
|
Acceleration time (10m)(loaded/unloaded)
|
6.5/8.6 sec
|
6.7/8.19 sec
|
6.6/8.14 sec
|
|
Weight
|
|
|
|
|
Total weight (with/without battery)
|
14705/13415 lb6670/6085 kg
|
15098/13558 lb6855/6150 kg
|
15890/14385 lb7210/6525 kg
|
|
Axle load (loaded front/rear)
|
7044/7727 lb3195/3505 kg
|
7088/7981 lb3215/3620 kg
|
7374/8521 lb3345/3865 kg
|
|
Axle load (unloaded front/rear)
|
2073/7288 lb941/3310 kg
|
2248/7252 lb1020/3290 kg
|
2473/7228 lb1121/3275 kg
|
|
Battery
|
|
|
|
|
Battery voltage/capacity
|
80/542 VAh
|
80/606 VAh
|
80/606 VAh
|
|
Battery weight
|
1290 lb585 kg
|
1510 lb685 kg
|
1510 lb685 kg
|
|
Motor and controller
|
|
|
|
|
Drive motor power(S2-60min)
|
28 HP20.5 kW
|
28 HP20.5 kW
|
28 HP20.5 kW
|
|
Lifting motor power(S3-15%)
|
35.5 HP26.5 kW
|
35.5 HP26.5 kW
|
35.5 HP26.5 kW
|
|
Steering motor power(S3-15%)
|
3.4 HP2.5 kW
|
3.4 HP2.5 kW
|
3.4 HP2.5 kW
|
|
Drive motor controlling mode
|
MOSFET/AC
|
MOSFET/AC
|
MOSFET/AC
|
|
Lifting motor controlling mode
|
MOSFET/AC
|
MOSFET/AC
|
MOSFET/AC
|
|
Steering motor controlling mode
|
MOSFET/AC
|
MOSFET/AC
|
MOSFET/AC
|
