Model
|
|
FB20
|
FB25
|
|
Power Type
|
|
Electric
|
Electric
|
|
Rated Capacity
|
kg
|
2000
|
2500
|
|
Load Centre
|
mm
|
500
|
500
|
|
Lift Height
|
mm
|
3000
|
3000
|
|
Fork Size（L×W×T）
|
mm
|
1070×120×40
|
1070×120×40
|
|
Mast Tilt Angle（F/R）
|
Deg
|
6°/12°
|
6°/12°
|
|
Front Overhang (Wheel center to fork face)
|
mm
|
465
|
465
|
|
Tread（F/R）
|
mm
|
960/950
|
960/950
|
|
Ground Clearance (Bottom of mast)
|
mm
|
110
|
110
|
|
Fork Spread（Min. / Max.）
|
mm
|
240/1020
|
240/1020
|
|
Overall Dimension - Length to face of fork(Without fork)
|
mm
|
2360
|
2360
|
|
Overall Dimension - Overall Width
|
mm
|
1160
|
1160
|
|
Overall Dimension - Mast Lowered Height
|
mm
|
2070
|
2070
|
|
Overall Dimension - Mast Extended Height(With backrest)
|
mm
|
4020
|
4020
|
|
Overall Dimension - Overhead Guard Height
|
mm
|
2240
|
2240
|
|
Turning Radius (outside)
|
mm
|
2075
|
2075
|
|
Min. insecting aisle
|
mm
|
2250
|
2250
|
|
Speed - Travel (Empty load)
|
km/h
|
15
|
15
|
|
Speed - Lifting(Full load)
|
mm/s
|
300
|
270
|
|
Max. Gradeability
|
%
|
15
|
15
|
|
Tire - Front
|
|
7.00 - 12 - 12 PR
|
7.00 - 12 - 12 PR
|
|
Tire - Rear
|
|
18×7 - 8 - 14 PR
|
18×7 - 8 - 14 PR
|
|
Wheelbase
|
mm
|
1510
|
1510
|
|
Service weight
|
kg
|
4170
|
4410
|
|
Motor - Drive Motor
|
kw
|
11
|
11
|
|
Motor - Lift Motor
|
kw
|
8.6
|
8.6
|
|
Battery - Voltage/Capacity
|
V/Ah
|
48/560
|
48/560
|
|
Controller - Manufacturer
|
|
CURTIS
|
CURTIS
|
|
Controller - Type
|
|
AC
|
AC
|
|
Operating Pressure for Attachment
|
Mpa
|
17.5
|
17.5
|
