Model
|
|
FD200
|
FD280
|
FD300
|
FD330
|
|
Power Type
|
|
Diesel
|
Diesel
|
Diesel
|
Diesel
|
|
Rated Capacity
|
kg
|
20000
|
28000
|
30000
|
33000
|
|
Load Centre
|
mm
|
1200
|
1200
|
1200
|
900
|
|
Lift Height
|
mm
|
4000
|
4000
|
4000
|
4000
|
|
Fork Size（L×W×T）
|
mm
|
2440×250×110
|
2440×250×110
|
2440×250×110
|
2440×250×110
|
|
Mast Tilt Angle（F/R）
|
Deg
|
5°/10°
|
5°/10°
|
5°/10°
|
5°/10°
|
|
Front Overhang (Wheel center to fork face)
|
mm
|
1240
|
1240
|
1240
|
1240
|
|
Ground Clearance (Bottom of mast)
|
mm
|
250
|
250
|
250
|
250
|
|
Overall Dimension - Length to face of fork(Without fork)
|
mm
|
6855
|
6855
|
6855
|
6855
|
|
Overall Dimension - Overall Width
|
mm
|
3050
|
3050
|
3050
|
3050
|
|
Overall Dimension - Mast Lowered Height
|
mm
|
4000
|
4000
|
4000
|
4000
|
|
Overall Dimension - Mast Extended Height(With backrest)
|
mm
|
6000
|
6000
|
6000
|
6000
|
|
Overall Dimension - Overhead Guard Height
|
mm
|
3500
|
3500
|
3500
|
3500
|
|
Turning Radius (outside)
|
mm
|
6500
|
6500
|
6500
|
6500
|
|
Min. insecting aisle
|
mm
|
8800
|
8800
|
8800
|
8800
|
|
Speed - Travel (Empty load)
|
km/h
|
25
|
25
|
25
|
25
|
|
Speed - Lifting(Full load)
|
mm/s
|
300
|
300
|
300
|
300
|
|
Max. Gradeability
|
%
|
20
|
20
|
20
|
20
|
|
Tire - Front
|
|
14.00 - 24
|
14.00 - 24
|
14.00 - 24
|
14.00 - 24
|
|
Tire - Rear
|
|
14.00 - 24
|
14.00 - 24
|
14.00 - 24
|
14.00 - 24
|
|
Wheelbase
|
mm
|
4650
|
4650
|
4650
|
4650
|
|
Service weight
|
kg
|
36800
|
38800
|
39600
|
40500
|
|
Battery - Voltage/Capacity
|
V/Ah
|
24/180
|
24/180
|
24/180
|
24/180
|
|
Engine - Model
|
|
TAD750VE
|
TAD750VE
|
TAD750VE
|
TAD750VE
|
|
Engine - Manufacture
|
|
Weichai
|
Weichai
|
Weichai
|
Weichai
|
|
Engine - Rated output/r.p.m.
|
kw
|
181/2300
|
181/2300
|
181/2300
|
181/2300
|
|
Engine - Rated torque/r.p.m.
|
N·m
|
1050/1500
|
1050/1500
|
1050/1500
|
1050/1500
|
|
Engine - No.of Cylinder
|
|
6
|
6
|
6
|
6
|
|
Engine - Bore×Stroke
|
mm
|
130×108
|
130×108
|
130×108
|
130×108
|
|
Engine - Displacement
|
cc
|
7150
|
7150
|
7150
|
7150
|
|
Engine - Fuel Tank Capacity
|
L
|
420
|
420
|
420
|
420
|
|
Transmission - Type
|
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
|
Transmission - Stage（FWD/RVS）
|
|
3/3
|
3/3
|
3/3
|
3/3
|
|
Operating Pressure for Attachment
|
Mpa
|
19
|
19
|
19
|
19
|
