Quick Details
Feature: Wheel Loader | Condition: New | Application: Construction |
Brand Name: SDLG | Model Number: LG952L | Certification: ISO,CE |
Rated Loading Capacity: 5.0t | Bucket Capacity: 2.7m3 | Dimension: 7600×3024×3349mm |
Max. Lifting Load: 5.0t | Engine: WD10G220E23 | Place of Origin: Jiangsu, China (Mainland) |
Warranty: 1 year | Color: Yellow | After-sales Service Provided: Engineers available to service machinery overseas |
Packaging & Delivery
Packaging Details: | Nude package Shipped by Ro-Ro or Bulk shipment |
Delivery Detail: | 7~15 days |
Main Features
1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly
|
Technical Parameters
Dimension | Unit | LG952L |
Overall length | mm | 7600 |
Overall width | mm | 3024 |
Overall height | mm> | 3349 |
Weight | | |
Total weight | kg | 16400~16450 |
Power | | |
Engine model | | WD10G220E23 |
Engine rated power | kW | 162 |
Engine rated speed | r/min | 2000 |
Travel | | |
Travel speed 1st (forward/backward) | km/h | 0~13/0~17 |
Travel?speed 2st (forward/backward) | km/h | 0~38 |
Main performance | | |
Rated load | t | 5.0 |
Bucket capacity | m3 | 2.7 |
Dumping clearance | m | 3.11~3.45 |
Dumping reach | m | 1.2~1.27 |
Max. breakout force | KN | ≥150 |
Max. traction force | KN | ≥160 |
Articulation angle | 0 | 38 |
Gradeability | 0 | 28 |
Wheel base | m | 2.84 |
Tread | m | 2.25 |
Tyre size | m | |
Min. ground clearance | m | 0.534 |
Min. turning radius | m | 5.765 |
Working speed | | |
Hydraulic cycle time – raise | s | |
Total hydraulic cycle time | s | ≤10 |
